TPU flat hose
Description
1.Construction:The hose consists of high tenacity polyester or aramid fiber as hose carcass,polyurethane as innerand outer tube layer which are extruded simultaneously.
2.Features:Abrasive resistance,acid and alkali resistance,oil resistance,corrosion resistance,aging resistance.In thecold environment,the hose will not become stiff,brittle and crack easily.
3.Application:The ideal large flow of long distance gas and liquid transportation,which widely used in petroleum.chemical,shipping,agriculture,water conservancy,mine rescue and firetighting.
4.Working temperature:-58℉-176℉(-40℃~80℃)
|
ID |
Thickness(mm) |
Weight(kg) |
BP |
WP |
|
4″( 100mm) |
3.2 |
3.8 |
15bar |
45bar |
|
5″(125mm) |
3.5 |
3.8 |
15bar |
45bar |
|
6″( 150mm) |
3.6 |
3.8 |
15bar |
45bar |
|
7″(175mm) |
4.0 |
3.8 |
15bar |
45bar |
|
8″( 200mm) |
4.2 |
3.8 |
13bar |
39bar |
|
10″( 250mm) |
4.8 |
4.5 |
13bar |
39bar |
|
12″( 300mm) |
5.2 |
5.0 |
10bar |
30bar |
